| RD-33# 300KG Specifications Overview | |
|---|---|
| Load Capacity | 300KG / Layer |
| Layers | Standard is 4 layers (can be custom made) |
| Colour | Gray white / Sand blue / Customizable |
| Specifications | Length: 2000 mm | Width: 450/600 mm | Height: 2000 mm |
The generated transportation costs on the page significantly differ from the actual transportation costs. You can share the product model, specifications, quantity, and delivery address to obtain an accurate shipping quote. If you have a Chinese freight agent, container loading and short-term storage services can be provided.
| Load / KG | Laminate Thickness | Column Specification | Crossbeam Specifications |
|---|---|---|---|
| 100KG | 0.30 mm | 50*25*0.5 mm | 50*30*0.5 mm |
| 200KG | 0.35 mm | 70*35*0.7 mm | 60*35*0.6 mm |
| 300KG | 0.50 mm | 60*30*1.0 mm | 70*33*1.0 mm |
| 600KG | 0.50 mm | 70*33*1.4 mm | 70*35*1.2 mm |
In order to have a better understanding of the product, please allow us to remind you with the following three tips:
Excellent quality, unique design, practical function, and enough variety are established as the core selling points. The trust and support from extensive customers have been won through consistent performance.
Operations are run for the purpose of "Integrity management, keep improving and innovative, win-win cooperation, professional production, high quality at low price, service first".
What is the standard load capacity of the RD-33# racking system?
The standard load capacity of the RD-33# system is 300KG per layer. Other options ranging from 100KG to 600KG per layer are also available depending on your specific requirements.
Can the dimensions and the number of layers be customized?
Yes. While the standard design features 4 layers, customized configurations regarding length, width, height, and layer count can be developed to suit your storage area.
What standard color choices are available?
The standard color options include Gray White and Sand Blue. Custom colors can also be prepared based on specific requirements.
How is the exact freight cost calculated?
The shipping cost displayed on the page is an estimate. For an accurate quote, please provide the desired product model, dimensions, quantity, and your delivery address.
Are container loading and storage services supported for local agents?
Yes, if you work with a freight agent in China, coordination is provided to offer container loading and short-term storage services at our facilities.
What types of storage systems can be designed?
A comprehensive design service is offered for warehouse racks, supermarket shelves, mezzanine racking systems, and mobile growing frames to optimize various spaces.
